Readouts at the last complete 100 ms hop within input. committedEnd is a source-frame position, not the caller's block boundary. pendingFrames are included in sample statistics but not loudness windows. integrated/range support bounds the complete windows supplied to gating; rejected windows inside that span do not contribute to the final value. More...
#include <AudioIntervalAnalyzer.h>
Public Attributes | |
| Interval | input |
| std::int64_t | committedEnd = 0 |
| int | pendingFrames = 0 |
| int | hopFrames = 0 |
| std::uint64_t | integratedBlocks = 0 |
| std::uint64_t | rangeBlocks = 0 |
| Measurement | momentary |
| Measurement | shortTerm |
| Measurement | integrated |
| Measurement | range |
Detailed Description
struct dspark::AudioIntervalAnalyzer< T >::Loudness
Readouts at the last complete 100 ms hop within input. committedEnd is a source-frame position, not the caller's block boundary. pendingFrames are included in sample statistics but not loudness windows. integrated/range support bounds the complete windows supplied to gating; rejected windows inside that span do not contribute to the final value.
Definition at line 67 of file AudioIntervalAnalyzer.h.
Member Data Documentation
◆ committedEnd
| std::int64_t dspark::AudioIntervalAnalyzer< T >::Loudness::committedEnd = 0 |
Definition at line 70 of file AudioIntervalAnalyzer.h.
◆ hopFrames
| int dspark::AudioIntervalAnalyzer< T >::Loudness::hopFrames = 0 |
Definition at line 72 of file AudioIntervalAnalyzer.h.
◆ input
| Interval dspark::AudioIntervalAnalyzer< T >::Loudness::input |
Definition at line 69 of file AudioIntervalAnalyzer.h.
◆ integrated
| Measurement dspark::AudioIntervalAnalyzer< T >::Loudness::integrated |
Definition at line 74 of file AudioIntervalAnalyzer.h.
◆ integratedBlocks
| std::uint64_t dspark::AudioIntervalAnalyzer< T >::Loudness::integratedBlocks = 0 |
Definition at line 73 of file AudioIntervalAnalyzer.h.
◆ momentary
| Measurement dspark::AudioIntervalAnalyzer< T >::Loudness::momentary |
Definition at line 74 of file AudioIntervalAnalyzer.h.
◆ pendingFrames
| int dspark::AudioIntervalAnalyzer< T >::Loudness::pendingFrames = 0 |
Definition at line 71 of file AudioIntervalAnalyzer.h.
◆ range
| Measurement dspark::AudioIntervalAnalyzer< T >::Loudness::range |
Definition at line 74 of file AudioIntervalAnalyzer.h.
◆ rangeBlocks
| std::uint64_t dspark::AudioIntervalAnalyzer< T >::Loudness::rangeBlocks = 0 |
Definition at line 73 of file AudioIntervalAnalyzer.h.
◆ shortTerm
| Measurement dspark::AudioIntervalAnalyzer< T >::Loudness::shortTerm |
Definition at line 74 of file AudioIntervalAnalyzer.h.
The documentation for this struct was generated from the following file:
